Technical Datasheet ∨
- Color:
Red | Yellow | Blue | Green | White | Clear
- Outside(L×W×H):
299.5×98.9×153.7mm
- Inside(top)(W×L):
85.5×255mm
- Inside(bottom)(W×L):
61×220mm
- Max. Height(H):
153.7mm
- Usable Height:
142.9mm
- Hanglock Height:
8mm
- Front Size:
53×81mm
- Weight:
207g
- Load Capacity:
30kg
- Hang Load Capacity:
20kg
- Material:
PP
- Temperature:
-25℃——40℃
- Accessories: Width Divider
SFH115
- Accessories: Front Plate
SFF100
- Drop Test(ISO2248-1985):
Pass 3 meters free fallen test
- Impact Test(Gardner Test):
≥104 in/Ibs
Specifications ∨
Packing Detail ∨
Carton size:405×310×405mm
Qty/ctn:20pcs/ctn
G.W.:4.8kg
Color label on the carton to show the part color
Other Details ∨
Width Dvider:SFH115
A5:1/2 divider slot
A4 A6:1/3 divider slot
A2 A4 A5 A6 A8:1/6 divider slot
Min. distance between slot:40mm
Front Plate:SFF100
